Call Flow Diagram - Screen Detailed Analysis for VoIP


Welcome to the master class of Sigma Telecom and today we are going to take a picture of a call and try to tell you about the flow of a VoIP call from beginning to end.


Flows are like roentgen of the VoIP calls that show the time of the call invitation, end, etc. It’s like taking a photo of the call. To look for the flow of a call you should select the call from the CDR screen and click on the flow button to see.


The Terms of The Flow of A Call

In the flow screen, you will meet with two main columns, the left side shows the connection between us and the customer; the right side shows the connection between us and our vendor. So what is the meaning of the terms for this flow?


Invite: The attempt for connecting the call


Invite (G729): The invite that comes with g729 codec


Invite (PCMU): Invite was transferred as PMCU to the vendor


100 Trying: This is the trial between the systems. The phone of the called one does not start to ring while 100 Trying and this time until hearing the ringtone means PDD.


Session Progress: The time of the ring of the called one’s phone. After this caller hears the ringtone.


200 OK: It means the called opened the phone


BYE: This means the phone call ended. Both sides can end the phone call. You can understand from the side that BYE code comes. For this flow, the person who closes the phone is the caller side.


Are you interested in more about VoIP business or need some professional help?

As Sigma Telecom we are one of the biggest VoIP provider companies in the world and with our knowledge and experience over 15 years, giving high-quality VoIP services to customers.


We are among the most known and trusted companies in the sector and have a partnership with the world’s biggest mobile operators like Etisalat, China Mobile, Belgacom, Orange, etc.

You can follow the latest news and developments by our social media accounts and feel free to ask anything about the VoIP business.
